Sauermann SI-30 Mini Piston Pump with Remote Detection Float Switch

SKU
SI-30
£87.53 £72.94
In stock

Sauermann SI 30 Mini Piston Pump with Remote Detection Float Switch

One pump for any air conditioner up to 20 kW. Sauermann patented technology inside, specifically designed for discharging condensates from air conditioning systems. Unequalled operating sound level, < 20 dBA, whatever the volume of condensates being discharged.

Applications:

  • Wall split systems
  • Consoles
  • Fan-coil units
  • Ceiling suspended
  • Ducted units

Benefits:

  • Unmatched sound level : < 20 dBA
  • Proven reliability
  • High performance
  • Energy saving

Technical Details:

  • Max flow rate: 20 l/h
  • Max suction head: 3m
  • Max discharge head: 10m
  • Electric power: 14 W
  • Electric voltage: 230 V~ 50/60 Hz
  • Alarm contact: NC 8 A resistive - 250 V
  • Detection levels in mm: On: 16, Off: 11, Alarm: 19
  • Sound level at 3.3ft: 20 dBA
  • Protection: IP20
  • Detection: remote
  • Thermal protection (overheating): 90 C
  • Safety standards: CE
  • RoHS and WEEE directives: complies
  • Pump Unit Dimensions: 66 mm (l) x 43.5 mm (w) x 60 mm (h)
  • Detection Unit Dimensions: 55 mm (l) x 38 mm (w) x 60 mm (h)

Kit contents :

  • Piston pump
  • Anti-vibration mounting bracket
  • Plug in power cable with 2 safety switch wires (1.5 m), 6 tie wraps
  • Detection unit SI2958, with cable
  • Installation kit: rubber elbow 90 int. dia. 15 x L 60mm, vent tube int. 4 x L 75 mm, mounting rail, adhesive.
More Information
Product NameSauermann SI-30 Mini Piston Pump with Remote Detection Float Switch
SKUSI-30
mpnSI-30
Brand c2cSauermann
Short Description

One pump for any air conditioner up to 20 kW. Sauermann patented technology inside, specifically designed for discharging condensates from air conditioning systems. Unequalled operating sound level, < 20 dBA, whatever the volume of condensates being discharged.

Description

Sauermann SI 30 Mini Piston Pump with Remote Detection Float Switch

One pump for any air conditioner up to 20 kW. Sauermann patented technology inside, specifically designed for discharging condensates from air conditioning systems. Unequalled operating sound level, < 20 dBA, whatever the volume of condensates being discharged.

Applications:

  • Wall split systems
  • Consoles
  • Fan-coil units
  • Ceiling suspended
  • Ducted units

Benefits:

  • Unmatched sound level : < 20 dBA
  • Proven reliability
  • High performance
  • Energy saving

Technical Details:

  • Max flow rate: 20 l/h
  • Max suction head: 3m
  • Max discharge head: 10m
  • Electric power: 14 W
  • Electric voltage: 230 V~ 50/60 Hz
  • Alarm contact: NC 8 A resistive - 250 V
  • Detection levels in mm: On: 16, Off: 11, Alarm: 19
  • Sound level at 3.3ft: 20 dBA
  • Protection: IP20
  • Detection: remote
  • Thermal protection (overheating): 90 C
  • Safety standards: CE
  • RoHS and WEEE directives: complies
  • Pump Unit Dimensions: 66 mm (l) x 43.5 mm (w) x 60 mm (h)
  • Detection Unit Dimensions: 55 mm (l) x 38 mm (w) x 60 mm (h)

Kit contents :

  • Piston pump
  • Anti-vibration mounting bracket
  • Plug in power cable with 2 safety switch wires (1.5 m), 6 tie wraps
  • Detection unit SI2958, with cable
  • Installation kit: rubber elbow 90 int. dia. 15 x L 60mm, vent tube int. 4 x L 75 mm, mounting rail, adhesive.
